Large Bottom Loading Furnace

Coverage Area: Johor, Melaka, Negeri Sembilan, Pahang, Selangor, Terengganu, Kelantan, Perak, Pulau Pinang, Kedah, Perlis, Sabah, Sarawak, Malaysia

Main Features
Manual Elevator or Electric lift bell type. Integrated Structure with elegant design. Vacuum forming ceramic fiber chamber or solid refractory brick as chamber materials Heaters: HRE resistance wire/SIC Rod / Mosi2 rod with different operating temperatures. SHIMADEN (Japan) Microprocessor Digital PID controller or any brand controller is available. Exhaust chimney valve is available for gas emission. Bottom floor available for all sides loading. CE compliant.

Main Features

Manual Elevator or Electric lift bell type.
Integrated Structure with elegant design.
Vacuum forming ceramic fiber chamber or solid refractory brick as chamber materials
Heaters: HRE resistance wire/SIC Rod / Mosi2 rod with different operating temperatures.
SHIMADEN (Japan) Microprocessor Digital PID controller or any brand controller is available.
Exhaust chimney valve is available for gas emission.
Bottom floor available for all sides loading.
CE compliant.

Technical Parameters

Model	Volume (L)	Chamber Size	Operate Temp (°C)	Voltage (V)	Max Temp (°C)	Heating Element
WTS-96-12A	96L	400x600x400	1100°C	380 V	1200°C	HRE
WTS-288-12A	288L	600x800x600	1100°C	380 V	1200°C	HRE
WTS-640-12A	640L	800x1000x800	1100°C	380 V	1200°C	HRE
WTS-1200-12A	1200L	1000x1200x1000	1100°C	380 V	1200°C	HRE
WTS-96-14A	96L	400x600x400	1300ºC	380 V	1400°C	SIC Rod
WTS-288-14A	288L	600x800x600	1300ºC	380 V	1400°C	SIC Rod
WTS-640-14A	640L	800x1000x800	1300ºC	380 V	1400°C	SIC Rod
WTS-1200-14A	1200L	1000x1200x1000	1300ºC	380 V	1400°C	SIC Rod
WTS-96-17A	96L	400x600x400	1600ºC	380 V	1700°C	Mosi2 Rod
WTS-288-17A	288L	600x800x600	1600ºC	380 V	1700°C	Mosi2 Rod
WTS-288-17A	288L	800x1000x800	1600ºC	380 V	1700°C	Mosi2 Rod
